Nave d'assalto anfibio
Amphibious assault ship
BATAAN
( Courage, Commitment, Honor )
Bandiera Flag U.S.A
Armatore Owner U.S. Navy
Impostazione chiglia Keel laid 22.06.1994
Varo Launched 15.06.1996
Entrata in servizio In service 20.09.1997
Cantiere navale Shipyard Litton-Ingalls Shipbuilding Corp. Pascagoula - MS
Costruzione n. Yard number
Tipo di scafo
Hull type scafo singolo - single hull
Nominativo Internazionale Call Sign N B A T -
I.M.O.       International Maritime Organization
M.M.S.I.   Maritime Mobile Service Identity
Numero d'identificazione ID number LHD - 5 (Landing Helicopter Deck)
Porto di base Home Port Norfolk - VA
Stazza Lorda Gross Tonnage

Dislocamento max

Displacement max 41.006 Tonn
Lunghezza max L.o.a. 256,0 m
Larghezza max
Breadth max 42,60 m
Altezza di costruzione Depth
Pescaggio max
Draught max 8,10 m
Motore principale Main Engine 2 - caldaie / boilers
2 - geared steam turbines
Potenza Motori Engine Power 70.000 Hp
Eliche di propulsione Propellers 2 - shafts
Velocità massima Max speed 23,0 kn
Armamento Arms 2 - RAM launchers
2 - NATO Sea Sparrow launchers
2 - 20 mm Phalanx (CIWS) mounts
4 - 50 cal. machine guns
4 - 25 mm Mk 38 machine guns
Strumentazioni
elettroniche
Electronic
equipments
AN/SLQ-49 Chaff Bouys
AN/SLQ-25 NIXIE Towed Torpedo Countermeasures
SRS-1 Combat D/F
AN/SLQ-32(V)3 Electronic Warfare (EW) system
1 AN/SPS-48 radar
1 AN/SPS-49(V)7 radar
1 AN/SPS-64 radar
1 AN/SPS-67 radar
AN/SYS-2 Detection/Tracking System
1 MK-23 Target Acquisition System (TAS)
1 MK-36 Chaff Launcher
MK-91 Fire control System
Velivoli
(dipende dalla missione)
Aircraft
(depends upon mission)
12 - CH-46 Sea Knight Helicopters
4 - CH-53E Sea Stallion helicopters
6 - AV-8B Harrier attack aircraft three UH-1N Huey helicopters
4 - AH-1W Super Cobra helicopters planned capability to embark      MV-22 Osprey VTOL tilt-rotors
Autonomia Range 9.500 a/at 20 kn
Equipaggio Crew

1.108 - 104 Ufficiali + 1004 Sottufficiali e marina
                 Officers -         Pretty Officers and sailors
1.894 - Marines

Navi gemelle Sister ship
Inserita
Posted
14.10.2014
Aggiornata Last updated
14.10.2014
INFORMAZIONI STORICHE


I dati e le informazioni sono stati ricavati dal sito della U.S. Navy

 HISTORICAL INFO

Data and information were obtained from the website of the U.S.Navy.
